Pipeline marking

for industry and plant engineering

Rohrleitungen für Rrohrleitungskennzeichnung

Signs with your desired text

Pipeline labeling with more than 40 years of experience in manufacturing

Regoplast® has more than 40 years of experience in the manufacture of weather-resistant signage systems. These are used in many areas of industrial and plant labeling.

On request, we can create signs according to your specifications and from various materials (PVC, Resopal® and underprint plates). Possible finishes: engraved, reverse printed and printed by digital or screen printing. Basically, we offer, in combination with different fastening materials, metal or plastic as a carrier material. Here, too, our sign holders or profile rails from the “Sign holders & plug-in signs” range are used as support elements.

Regoplast® medium markings for supply lines in printed or engraved versions are largely UV-stabilized, scratch-resistant and resistant to acids, alkalis and other chemicals. As a result, they have a longer service life than conventional signs. Colors according to DIN 2403/2404.

Medium identification for supply lines on pipe bridges etc.

Size in mm (LxH)Base colour / font colourPackaging unit
Text
Font height in mmItem no.
185 x 83.5yellow / blackpieceAbluft (Exhaust air)53 241200
445 x 83.5yellow / blackpieceACETYLEN (ACETYLENE)53 241201
280 x 83.5yellow / blackpieceARGON53 241202
170 x 83.5yellow / blackpieceBAR53 241203
300 x 83.5yellow / blackpieceErdgas (Natural gas)53 241204
335 x 83.5 yellow / blackpieceERDGAS (NATURAL GAS)53 241205
475 x 83.5 yellow / blackpieceFORMIERGAS (FORMING GAS)53 241206
280 x 83.5 yellow / blackpieceHELIUM53 241207
525 x 83.5 yellow / blackpieceKOHLENDIOXID (CARBON DIOXIDE)53 241208
300 x 83.5 yellow / blackpiecePROPAN53 241209
460 x 83.5 yellow / blackpieceSTICKSTOFF (NITROGEN)53 241210
585 x 83.5 yellow / blackpieceWASSERSTOFF (HYDROGEN)53 241211
340 x 83.5 yellow / blackpieceWasserstoff (Hydrogen)53 241212
105 x 83.5 red / whitepiecebar53 241220
185 x 83.5 red / whitepieceDampf (Steam)53 241221
265 x 83.5 grey / blackpieceArb.-Luft (Work air)53 241230
105 x 83.5 grey / blackpiecebar53 241231
330 x 83.5 grey / blackpieceBetriebsluft (Operating air)53 241232
290 x 83.5 grey / blackpieceInstr.-Luft (Instr. air)53 241233
435 x 83.5 grey / blackpiecePRESSLUFT (COMPRESSED AIR)53 241234
475 x 83.5 grey / blackpieceSYNTH.-LUFT (SYNTH. AIR)53 241235
265 x 83.5 grey / blackpieceRegelluft (control air)53 241236
280 x 83.5grey / blackpieceFörderluft (conveying air)53241237
635 x 83.5 white / blackpieceLEERE FLASCHEN (EMPTY BOTTLES)53 241240
475 x 83.5 blue / whitepieceSAUERSTOFF (OXYGEN)53 241250
290 x 83.5 purple / white pieceAmmoniak (Ammonia)53 241260
Regoplast lettering boards suitable for sign holder yard goods 86.5 mm height. Order No. 110032
